D-Link DGS-1005P | 5-Port Gigabit Unmanaged Desktop Switch
5-Port Gigabit Unmanaged Desktop Switch
Supports PoE
The D-Link DGS-1005P is a 5-port Gigabit switch designed for home and small business use. It features high-speed networking, including four PoE (Power over Ethernet) ports, allowing you to connect devices like IP cameras, phones, and wireless access points without needing separate power supplies. Its compact, fanless design ensures silent operation, making it perfect for noise-sensitive environments like offices or conference rooms.
Documents
D-Link DGS-1005P | 5 port Gigabit Unmanaged Desktop Switch,
The DGS-1005P is a high-performance network switch that boasts five Gigabit Ethernet ports, each capable of delivering full-duplex speeds of up to 1000 Mbps. This device is compliant with the IEEE 802.3af and IEEE 802.3at Power over Ethernet (PoE) standards, allowing it to provide up to 30W of power per port, with an overall power budget that reaches 60W. One of the standout features of this switch is its plug-and-play installation, which means users can set it up quickly and easily without the need for any complex configuration. Furthermore, it incorporates automatic MDI/MDI-X technology, which simplifies the connection process by eliminating the necessity for crossover cables, making it user-friendly for both novices and experienced network administrators. In addition to its robust performance capabilities, the DGS-1005P is designed with energy efficiency in mind, utilizing advanced green technology that intelligently adjusts power consumption based on the current network activity and the length of the connected cables. This not only helps in reducing operational costs but also contributes to a more sustainable and environmentally friendly networking solution.
D-Link DGS-1005P details
Technical Specifications
Network Ports & Connectivity
- 5 x 10/100/1000BASE-T Ethernet ports
- Auto MDI/MDI-X on all ports
- IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
- IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet
- IEEE 802.1p QoS
- Link status detection
Performance & Management
- Wire-speed filtering
- Store-and-forward switching scheme
- Auto-negotiation on each port for optimal speed
- IEEE 802.3x flow control
- Energy-efficient Ethernet (EEE)
- Cable length detection
PoE (Power over Ethernet)
- 4 PoE ports
- IEEE 802.3af/at compliant
- Up to 30W power output per PoE port
- Total power budget: 60W
- Provides power to devices such as IP cameras, wireless access points, and IP phones without additional power supplies
Physical & Environmental
- Compact desktop form factor
- Fanless design for silent operation
- RoHS-compliant
- Operating temperature range: 0°C to 40°C (32°F to 104°F)
- Storage temperature range: -20°C to 65°C (-4°F to 149°F)
- Humidity: 10% to 90% non-condensing
Box Contents
Your D-Link DGS-1005P box comes with:
Your Switch
- D-Link DGS-1005P Switch console
Accessories
- Power Adapter (DC 12V, 1A
Additional items
- User Guide
