D-Link DGS-1210-10MP | 10-Port Gigabit Smart Managed PoE Switch
8 10G BASE-T (PoE++) ports • 2 SFP+ ports
Gigabit Smart Managed Switch
The D-Link DXS-1210-10MP is a powerful, multi-gigabit managed switch designed to handle demanding network environments. It offers a blend of advanced features, such as 8 versatile Ethernet ports supporting up to 10G speeds and 2 high-speed 10G SFP+ ports. Ideal for growing businesses or data centers, this switch ensures reliable connectivity and can scale with your network’s evolving needs.
Documents
D-Link DGS-1210-10MP | 10G Multi-Gigabit Smart Managed Switch
The D-Link DXS-1210-10MP is an advanced 10G Multi-Gigabit Managed Switch, engineered to deliver high performance and exceptional reliability. It features 8 100M/1G/2.5G/5G/10G BASE-T ports, each supporting Power over Ethernet (PoE++), making it perfect for powering network devices such as IP cameras or VoIP phones. Additionally, there are 2 10G SFP+ ports for ultra-fast fiber connectivity, allowing seamless integration into high-demand networks. The switch supports a range of network standards including IEEE 802.3bz (2.5G/5G Ethernet), IEEE 802.3an (10GBASE-T), and more, providing flexibility in network setup. With a switching capacity of 200 Gbps and a maximum packet forwarding rate of 148.8 Mpps, the DXS-1210-10MP can handle heavy traffic without compromising performance. Security features such as port security, ACLs, DoS prevention, and DHCP server screening ensure your network remains safe. The device also supports advanced network management tools like D-Link Nuclias Connect, CLI, SNMP, and web-based management, making it simple to configure and monitor your network.
D-Link DGS-1210-10MP
details
Technical Specifications
Network Ports & Connectivity
- 24 x 10/100/1000BASE-T ports
- 4 x 100/1000 Mbps GbE/SFP combo ports
- IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z support
- Auto MDI/MDIX adjustment for all twisted-pair ports
- UTP Cat. 5, Cat. 5e (100m max)
Performance & Management
- Switching Capacity: 50 Gbps
- Maximum Forwarding Rate: 77.4 Mpps
- MAC Address Table: 8K entries
- CPU Memory: 256 MB DDR3, Flash Memory: 32 MB
- Store-and-forward forwarding method
PoE (Power over Ethernet)
- 24 x 10/100/1000BASE-T PoE ports
- IEEE 802.3at compliant PoE support
- Maximum PoE power budget: 130W
- Auto detection for powered devices (PD)
- PoE on/off control for each port
Security & VLAN Features
- IEEE 802.1Q VLAN support
- Static MAC address up to 256 entries
- IEEE 802.3x Flow Control
- Broadcast/Multicast/Unicast Storm Control
- PoE on/off control
Physical & Environmental
- Fanless design
- Dimensions: 440 x 430 x 44 mm
- Operating Temperature: -5 to 50°C (23 to 122°F)
- Weight: 2.91 kg (6.42 lbs)
- Power Surge Protection: 6KV
Box Contents
Your D-Link DGS-1210-10MP box comes with:
Your Switch
- D-Link DGS-1210-10MP PoE Switch console
Accessories
- Power Cable
- Ethernet Cable
Additional items
- User Guide
