D-Link DMC-540SSC 10/100Base-TX Fast Ethernet Twisted-pair to 100Base-FX Fast Ethernet Fiber
D-Link DMC-540SSC 10/100Base-TX Fast Ethernet Twisted-pair to 100Base-FX Fast Ethernet Fiber 1310nm Single-mode Fiber (40 km, SC) Media Converter EU/UK plug
Part Number: DMC-540SSC
Media converters convert signals that are transmitted from one
type of media to another so that they can be transmitted over a
different type of media. This series of media converters converts
10/100/1000 Mbps copper ethernet to a 100/1000 Mbps fibre optic
connection connection.This allows you to expand your network by
connecting longer distance,cables between devices that are
otherwise connected with short distance Ethernet cables, such as Cat.6
twisted-pair cables.
|
DMC-540SSC |
|
Interface |
|
|
Number of Ports |
• 1 x 10/100BASE-TX RJ-45 port • 1 x 100BASE-FX SC port |
|
Standards |
• IEEE 802.3 for 10BASE-T/F • IEEE 802.3u for 100BASE-TX/FX |
|
Data Transfer Rate |
• Ethernet: 10 Mbps/20 Mbps (half- duplex/full-duplex) • Fast Ethernet: 100 Mbps/200 Mbps (half-duplex/full-duplex) |
|
Duplex Mode |
• Half-duplex/full-duplex |
|
Media Types |
• 10BASE-T: 2-pair Cat. 3/4/5/5e, Unshielded Twisted Pair (UTP) (up to 100 m) • 10/100BASE-TX: 2-pair Cat. 5/5e, Unshielded Twisted Pair (UTP) (up to 100 m) • 100BASE-FX: Multi-mode fi optic cable with SC connector (up to 40 km) |
|
Media Exchange Interface |
• Auto-MDI/MDIX |
|
Functionality |
|
|
Transmission Mode |
• Store-and-forward |
|
Forwarding Rate |
• Full wire-speed forwarding rate |
|
Physical |
|
|
Diagnostic LEDs |
• Power • Speed (for twisted pair ports) • Full-duplex/Collision (for twisted pair and fi ports) • LINK/ACT (for twisted pair ports) |
|
AC Input |
• 5 V/1 A external power adapter |
|
Temperature |
• Operating: 0 °C to 50 °C • Storage: -20 °C to 70 °C |
|
Humidity |
• 5% to 90% RH, non-condensing |
|
Dimensions |
• 95x 70 x 26 mm |
|
Fiber Wavelength |
• 1310 nm |
|
Supported Fiber Cable Length |
• Up to 40km |
|
Emission Certifi tions (EMI) |
• FCC |
